Electro Hydraulic Thruster


Electro Hydraulic Thruster 01 Electro Hydraulic Thruster 02

Thruster is an electro hydraulic device, designed to exert acontast force to any mechanism to be operated. The Thruster work on a principle of hydraulics. On supply of eectric power, motor driven centrifugal impeller draws the oil from the low pressure end of the chember to the high oressure upper end. The piston mounted on the same shaft moves to the upper end with full thrust, till its movement is stopped by the stopper shoulder at the end of the stroke. Pressure build up stops when power is discontinued. Radialblade design of the impeller enables it to rotate both in clockwise and anticlockwise direction. Therefore power supply to star connection can be in any R-Y-B phase sequence.

Special Features :

  • Packaged self contained unit-No external piping and accessories required.
  • Self aligned movement
  • Rated force available for the entire stroke
  • Compatible for use with any exiting or new system.
  • Low power consumption
  • Moving parts being immersed in oil, No frictional losses.
  • Minimum maintenance.


Thruster Set 520 :
A compact 90 watt, 415 volts, 50 cycles, 3 phase Electric motor is directly mounted on the top of a piston. The piston is housed in the C.I. Tank filled with fluid. The piston moves the fluid from low pressure are to high pressure area. The specially designed impeller which is mounted on the motor shaft produces required fluid pressure.

Thruster : ST 535 tost 13300


This range of two thrust rods and a common piston. The motor is mounted on the top cover of the tank. A separator plate divides the tank in two partitions-low pressure side and high pressure side. The spacer bushes control the thruster.


The models are suitable for large capacity, Higher motor ratings and larger thruster forces.

Maintenance :
The thruster is designed for long trouble free service and needs no maintenance. The motor bearings are adequately sized and windings are designed to meet the sudden jerks and shocks. Normal maintenance like topping of the oil levels replacement of damaged worn out oil seal and gaskets is required. The terminal box must be cleaned periodically.



Specification

Type Rated Output Input Dimensions in mm Weight (kg) Oil Capacity Litres
Thrust Kgs. Stroke mm Watts A B C D E F G H J K L M N P Q
ST 520 18 51 90 349 51 59 19 25 13 12.7 19 16 19 32 19 306 121 30 14 2
ST 535 34 51 150 444 51 171 22 29 14 19.1 22 21 27 41 25 250 138 110 30 2.5
ST 546 45 51 180 444 51 171 22 29 14 19.1 22 21 27 41 25 250 138 110 30 2.5
ST 870 68 76 200 508 76 216 25 32 16 22.2 25 24 29 48 32 292 152 124 40 4.5
ST 8110 114 76 250 508 76 216 25 32 16 22.2 25 24 29 48 32 292 152 124 40 4.5
ST 13200 225 127 420 660 127 254 32 38 19 25.4 29 27 43 54 38 381 152 127 55 9
ST 13300 295 127 580 660 127 254 32 38 19 25.4 29 27 43 54 38 381 152 127 55 9
